Product description

Highlight Features
2.5GE uplinks, overcoming GE limitations, supporting diverse access types, and enabling integration into 10GE networks
Unique CPU protection policy, ensuring stability of the switch and nonstop services
RLDP used to provide smooth network connections
10 kV surge protection for ports and high reliability
Compliance with standard protocols and application in various scenarios
Ease of use through Ruijie Cloud for management and remote O&M

Key Specification
Fixed Service Ports: 10 × 10/100/1000BASE-T ports, ports 1 to 8 supporting PoE/PoE+
2 × 1GE/2.5GE SFP ports
Management port: 1 x RJ45 console port
Switching capacity: 30 Gbps
Forwarding rate: 22.5 Mpps
Capacity of MAC address table: 16000
Power module: 1 x fixed power module
Fan module: 1 x fan module
Cooling mode: Fan cooling
Input power: “Rated input voltage range: 100V AC to 240V AC, 50/60Hz
Max. input voltage range：90V AC to 264V AC, 50/60Hz”
Power consumption: 141W (PoE budget: 125W)
Surge protection 10 kV
Dimensions (W x D x H): 297 mm × 170 mm × 44.5 mm (11.69 in. x 6.69 in. × 1.75 in.)
Temperature: “Operating temperature: 0°C to 45°C (32°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)”
Warranty: 3 years
